SRICAM SP023 1080P WiFi Outdoor Waterproof IP Camera Support Onvif Micro SD Card - US Plug
AP Hotspot: Supports set and view the camera via AP Hotspot
Onvif Protocol: Supports NVR recording and playback
Micro SD Card: Supports max 128GB Micro SD card for recording and playback
Alarm: Supports motion detection alarm, phone push alarm, Email alarm
Night Vision: 2pcs array LEDs, IR distance up to 15m
IP66 Waterproof: Suitable for indoor and outdoor use, all-weather environment application
Specification:
| Model No.: SP023 | ||
| System | Main Processor | High-performance processor |
| Operating System | Embedded Linux OS | |
| Image Sensor | Sensor | High definition color CMOS sensor |
| Display Resolution | 1920x1080 (2.0 Megapixel) | |
| Minimum Illumination | 0.1 Lux / F1.2 (With IR Illuminator) | |
| Lens | Lens Type | Metal glass lens |
| Lens Parameter | Focal length: 3.95 mm. Aperture: 2.4 | |
| Angle of View | Horizontal: 73°, Vertical: 53.6°, Diagonal: 95.2° | |
| Video | Resolution | 1080P(1920x1080), VGA(480x360) |
| Image Compression | H.264 | |
| Zoom | Sricam App supports 4x digital zoom | |
| Image Frame Rate | 25 fps maximum | |
| Image Adjustment | Automatic | |
| Infrared Mode | Automatic | |
| Night Visibility | 2 Pcs array LEDs, IR distance up to 15 meters | |
| Filter Switch(IR-Cut) | Built-in IR Cut, no color deviation indoor or outdoor | |
| Record | Micro SD Card | Supports up to 128GB micro SD card for recording and playback |
| Recording Mode | Motion Detection alarm recording, Timing recording and Manual recording | |
| Record Standard | HD @ 25 fps | |
| Storage Path | Supports recording on micro SD card, smart phone or Windows PC | |
| Playback | Supports remote and local record playback | |
| Network | Ethernet | RJ-45 Ethernet |
| Wireless | IEEE 802.11 b/g/n, security supports WEP, WPA & WPA2 encryption | |
| Online Visitor | Supports max 4 visitors at same time | |
| Onvif Protocol | Supports NVR real time monitoring, recording and playback | |
| AP Hotspot | Supports set and view the camera via AP Hotspot | |
| Alarm | Alarm | Supports Motion detection alarm, Phone push alarm and Email alarm. The alarm video will automatically record on the micro SD card |
| Others | Product Type | Metal gun type, waterproof outdoor use |
| DC Power | DC12V, 1A | |
| Working Temperature | -10 to +50℃ | |
| Working Humidity | 10% to 90% RH | |
| Size | Item size: 165mm x 68mm x 64mm (LxWxH) | |
| Weight | N.W.: 360g | |
| System Required | Sricam App | Supports iOS and Android system smart phones or tablet PCs |
| For Windows PC | "SricamPC" App Supports 1-, 4-, 6-, 8-, 9, 16- Channel IP Camera centralized monitor, record and playback on Windows PC | |
| Certification | CE, FCC & RoHS | |
