• Using 2.4GHz as transmission frequency, comply with the standards pursuant to FCC, CE

• High definition 2.4 inch display

• Supports one main device operating with multi sub-devices, one receiver can be connected to 4 transmitters

• Supports long distance transmission, max to 200m-300m in empty area

• High resolution night vision function, can achieve 24 hours monitor

• Using half-duplex communication, ensues clear sound quality

• Including VOX (voice control) auto wake-up function

• The receiver operates with lithium battery which provides convenience for mobile using

• Includes "Pairing" function, which can pairing devices by pressing the "pairing" button on the LCD receiver end and the camera end

• Supports playing music for baby

Specification:

• LCD size: 2.4-inch 960x240 RGB LCD

• LCD receive voltage: DC: 5V/1000mA

• Battery: Built-in 3.6V/700mAh Li-battery

• Transmission frequency: 2.4GHz ISM Band

• Wireless working method: FHSS

• Transmission power: 19dBm@CW mode

• Transmission speed: 3Mbps

• Transmission distance: 200-300 meters in open area

• Working electric current: TX: 400mA max, RX: 400mA max, stand-by 160mA (without charging electric current)

• Charging electric current: 120-200mA

• Audio collect speed: 16K

• Audio frequency response range: 120Hz~3KHz

• MIC input: 35~50dB

• Camera resolution: 0.3 mega pixels

• Image resolution: 20x240QVGA

• Video FPS: 15-25FPS

• Total harmonic distortion: <5.0%

• Signal to noise ratio: 46dB

• Reception sensitivity: -96dBm@BER=1e-3

• Night vision distance: 2~3 meter

• Humidity: 20~80% RH

• Temperature: 0℃~45℃
