1/4" 1.0 Megapixel progressive scan CMOS
IR night vision, 3.6mm lens, IR distance is 15m
Supports standard ONVIF
Power over Ethernet (PoE) setup is clean and simple with a single network cable
Specifications:
Model | QE07 | |
Camera | ||
Image Sensor | 1/4'' 1.0 Megapixel progressive scan CMOS | |
Effective Pixels | 1280(H) x 720(V) | |
Scanning System | Progressive | |
Electronic Shutter Speed | 1/50s(1/60s)-1/100, 000s | |
Min. Illumination | Color: 0. 2Lux, B/W: 0.08Lux | |
S/N Ratio | ≥39dB | |
Camera Features | ||
Max. IR LEDs Length | Dual IR-CUT Filter auto switch, 18pcs Microcrystalline Array Led, IR Range 15m | |
Day/Night | Auto(ICR) / Color / B/W | |
Backlight Compensation | BLC/ HLC / DWDR | |
White Balance | Auto / Manual | |
Gain Control | Auto / Manual | |
Noise Reduction | 3D | |
Privacy Masking | Up to 4 areas | |
Lens | ||
Focal Length | 3.6mm | |
Max Aperture | F1.4 | |
Angle of View | 62.2° | |
Mount Type | MTV mount | |
Video | ||
Compression | H.264 | |
Resolution | 720P(1280*720), D1(704*576), CIF(352*288) | |
Frame Rate | Main Stream | 720P (1 ~ 25fps) |
Sub Stream | D1/CIF (1 ~ 25fps) | |
Bit Rate | CBR/VBR, output bit rate range: 48~3072kbps | |
Network | ||
Ethernet | RJ-45 (10/100Base-T) | |
Protocol | TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, DNS, DDNS, DHCP, NTP, PPPOE, SMTP, UPNP | |
ONVIF | ONVIF2.0 | |
Max. User Access | 4 users | |
Smart Phone | iPhone, iPad, Android | |
General | ||
Power Supply | DC12V, PoE (IEEE802.3af) | |
Temeperature | -10°C~50°C | |
Power Consumption | <6W | |
Ingress Protection | IP66 | |
Package size | 190mm x 90mm x 95mm | |
Weight | Gross Weight: 480g(Note: in kind prevail) | |
Approvals | CE FCC RoHS |
