• 3-in-1 functions: extend WiFi signal, turn wired network to wireless, mini router for home use

• Designed with external 2*2dBi dual band antenna for better signal and longer distance

• One Key to Repeater: Press the WPS button on the router and then press WPS button on the device within 50 seconds, then you can extend WiFi signal successfully

Specifications:

• Chipset: RTL8196EU+8192ER

• Standard: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u

• Input Power:100V-240V AC

• Frequency: 2.4~2.4835GHz

• Transmission Rate: 11n: Up to 300Mbps (dynamic); 11g: Up to 54Mbps (dynamic); 11b: Up to 11Mbps (dynamic)

• Connecting Port: 1RJ45 LAN port

• RF Outyput Power: 15-17dBm (power can be adjusted)

• Antenna: Extenal 2dBi antenna x 2

• Modulation Mode: DBPSK, DQPSK, CCK, OPDM, 16-QAM, 64QAM

• Certification: CE, FCC, CCC, ISO9001

• Operation System: Windows 98SE, Windows7, Me, 2000, XP, Vista, MAC, Linux, etc.

• Indoors: 25-50m

• Response Rate: 300M: -68dBm@10%PER; 130M: -68dBm@10%PER; 108M: -68dBm@10%PER; 54M: -68dBm@10%PER; 11M: -68dBm@10%PER; 6M: -68dBm@10%PER; 1M: -68dBm@10%PER
