• Ambarella A12A55, OV4689 1/3 inch COMS, 150-degree wide angle lens

• HDR function, built in GPS, HDMI output, H.264, G-Sensor function, ADAS function support (LDWS, FCWS)

• Video Resolution: 2560x1440P(30fps) / HDR2560x1440P(30fps) / 2304x1296P(30fps) / 1920x1080P(60fps) / HDR1920x1080P(30fps) / 1920x1080P(30fps)

• Loop-cycle Recording, Auto-Power On/Off, Motion Detection, Parking Mode, Delay Shutdown

Specifications:

• Model: DAB211

• Solution: Ambarella A12A55 + 2.31'' LCD + 2 DDR3 + 1Gbit Flash + OV4689 + Lens TRC-2045E1 (diameter14mm)

• Image sensor: 4.0MP 1/3'' CMOS


• Startup picture LOGO: According to demand


• Lens quantity: 1PCS


• Front view lens model: TRC-2045E1+5001C-


• Focal length: f=2.95mm


• Diagonal angle: 143-degree wide angle


• Aperture: F/1.8


• LCD: 2.31-inch

• Video resolution: 2560x1440 30P/HDR 2560x1440 30P/2304x1296 30P/1920x1080 60P/1920x1080 30P/HDR 1920x1080 30P/1280x720 60P


• Video codec.: H.264


• Video frame rate: 60fps/30fps


• Pixels: 4M/8M/14M/16M


• Photo format: JPG

• Microphone/speaker: Built-in

• Video format: MP4

• Audio format: AAC

• Working voltage: Use car charger MICRO USB 5PIN: 5V1.5A (1.5A) 1 positive 5 negative ontology USB charging

• Power input: Car charge MICRO 5PIN (1+ 5-)

• Battery capacity: 400mA/3.7V

• Languages: Simplified Chinese / English

• Default language: Default English

• GPS: Built in 18*18*6.7MM

• Size: 75*64.7*42.6MM

• Indicator light: Charge red light / boot blue light / video blue light flash

• Built-in memory: 1Gbit

• Memory card: TF (Support Max 64GB )

• USB function: MICRO USB 5PIN

• Support function: TF card reading function, camera function, USB connection, HDMI

• SOS/G-SENSOR: LIS3DH

• Default light source frequency : 50Hz

• Key definition: Power key / Reset button / MENU key / Up key / Down key / OK video button / MODE key
