• Safety arming feature: regardless the throttle stick position, the motor will not spin after battery connected

• Throttle calibration function: throttle range can be calibrated to be compatible with different transmitters

• User programmable

• Multiple program methods supported: transmitter stick, LED Program Card

• Very easy to program the ESC at home or at the flying field

• Compatible with Lipo and NiCd/NiMH batteries

• Timing can be changed to be suitable for different brushless motors

• Full protection: low voltage cutoff protection / over-heat protection / throttle signal loss protection

Specification:

• Output: Continuous 40A, Burst 55A up to 10 seconds

• Input Voltage: 2-3 cells Lipo battery or 5-9 cells NiCd/NiMh battery

• BEC Mode: 5V / 3A (Linear mode)

• Refresh Rate: 50Hz - 432Hz

• Max. Speed: 210000rpm for 2 poles BLM, 70000rpm for 6 poles BLM, 35000rpm for 12 poles BLM (BLM = Brushless Motor)

• Size: 68mm x 25mm x 8mm

• Weight: 39g
